The Sanicubic 1 VX is a powerful floor-standing lifting station designed for larger domestic installations and light commercial environments such as restaurants, cafés, small shops and multi-fixture buildings.
This IP68 rated lifting station features a 60 litre capacity tank and a high-performance vortex pump, designed to transfer wastewater from toilets, bathrooms, kitchens and laundry appliances. The vortex impeller helps reduce the risk of blockages by allowing solids to pass through the pump more freely. When the tank reaches a pre-set level, the pump activates automatically to discharge waste through pipework to a suitable outlet – such as a mains sewer, septic tank or external holding tank.
The unit includes three inlet connections, allowing multiple fixtures to be connected to the same pumping station. Discharge pipework should typically be DN40 (40mm) diameter, continuing from the outlet to the final drainage point.
Supplied as standard, the Sanicubic 1 VX includes an external control box with visual and audible alarm, providing early warning of high water levels or operational faults. The design also allows direct access to the motor and level sensors, simplifying routine maintenance and servicing.
With its IP68-rated motor and robust construction, the Sanicubic 1 VX is designed for reliable operation in demanding residential or commercial applications where gravity drainage is not possible.
For detailed product information, data sheets and installation instructions please consult the downloads section on this page.
